Feature:

• Concentration Equipment is for concentration after extraction of extraction of Chinese herbal medicine, tea, coffee, Health food, and biotechnology.
• Follow the regulation of cGMP, PIC/S, GMP.
• Rising membrane evaporator is suitable for mass production.
• Equipped with temperature detector.
• The inner tube of the heater is made of seamless steel pipe, and the inner diameter of the pipe is polished.
• The machine uses a new man-machine interface control, touch screen, easy to operate, multi-mode memory can be modeled.
• Heat exchanger: all made of sanitary pipe.
• High condensing efficiency, available circulating cooling water, doesn’t need to use ice machine, can according to customer’s demand.
• Small horsepower to achieve high vacuum level, can save more energy.
• Low temperature concentration: 45 ~ 60°C.
• The vacuum level can reach -650 ~ 720mm Hg
• In the process of concentration, water and alcohol can be recovered, alcohol recovery rate as high as 80%, can reduce costs.
