Feature:

• Fluid Bed Spray Granulator - Dryer (Single Hose Pipe) is widely used in chemical, food and pharmaceutical, for the powder and spray granulate and drying of the powder, particle.
• Follow the regulation of cGMP, PIC/S, GMP.
• It’s a multifunctional machine that works for powder particle drying, powder granulating, micro-pellet granulation, micro-pellet film coating.
• The hot air source undergoes preliminary filtering, intermediary filtering and then high-efficiency filtering to thoroughly clean the inlet air source.
• The temperature can be divided into high-temperature drying or low-tem perature dehumidifying system and therefore becomes low-temperature drying.
• The drying efficiency is 10~20 times greater than the general oven.
• Air volume control using proportional automatic damper control.
• The control system adopts PLC automated control that can be operated via man-machine interface and read all temperature parameters, or convert files to print the temperature parameters.

Optional:

• Explosion proof system. (when organic solvent is used)
• The de-humidify device of the air inlet system.
• Precise and stable PID temperature control.
• Air volume control using proportional automatic damper control.
• WIP system.
• Vacuum feeding or discharge device.
• Dust collector system.
